Name: High Performance DELL Unity XT 680 680F 384G with 2*Intel Cpu Storage Array Server
Brand: Xiamen Dongchengxing Information Technology Co., Ltd.
Availability: InStock

Home Products Storage

High Performance DELL Unity XT 680 680F 384G with 2*Intel Cpu Storage Array Server

Product Details:

Place of Origin:	Fujian, China
Brand Name:	DELL

Contact Now

Detailed Product Description

Private Mold:	Yes	Products Status:	Stock
Capacity:	8PB

Product Description

Dell UNITY XT HFA and AFA store

The Dell Unity XT storage array is designed for high performance and a simplified multi-cloud journey, and optimized for efficiency gains, designed to simplify the IT transformation process and unleash IT
The full potential of data capital. Both Unity XT arrays, HFA and AFA, have more memory and up to 2 percent IOPS improvements compared to previous Dell Unity models
The number of drives increased by up to 50%. These cost-effective storage systems are equipped with dual active controllers and include a rich suite of all-inclusive, enterprise-grade software.
Unity XT AFA guarantees a future-proof 3:1 data reduction rate, while Unity XT HFA is ideal for the speed and low latency that do not require NVMe architecture Of the workload.

architecture

The Unity XT storage system implements an integrated unified architecture for data blocks, files, and VMware vVols with parallel support for native NAS, iSCSI, and Fibre Channel protocol. Each system features dual active storage processors, full 12 Gb SAS backend connectivity and Dell's patented multi-core architecture operating environment, from While delivering superior performance and efficiency in multi-cloud interoperability. Add additional storage capacity through Disk Array Storage modules (DAE).

Specification

Features			Technical Specification
Minimum/maximum number of drives			Minimum 6 SSD or 10 HDD Max. 1000
Array storage module			One 2U Disk Processor Enclosure (DPE) with 25 2.5" drives
RAID options			1/0、5、6
CPU per array			2 dual Intel cpus, each array of 48 cores,2.1 GHz
System memory			384G
The maximum FAST of each array Cache capacity			Up to 3.2 TB
Total cache capacity			Up to 3.58TB
Maximum number of sandwich cards per array			2
Maximum number of I/O modules per array			4
Each array embedded SAS IO Port number			Four 4-channel 12Gb/s SAS Port (for BE connection Pick up)
Optional SAS I/O for each array port			NA
Each array supports the basics 12Gb/s Number of SAS BE buses			two 4 channels
Maximum value supported by each array 12Gb/s Number of SAS BE buses			6 4 channels or 2 4 channels and 2 8 channels
The maximum FE (before End) Total number of ports (all classes Type)			24
Maximum number of initiators per array The amount			2,048
Maximum number of Fibre Channel ports on each array			16
Embedded CNA for each array Number of mouths			NA
Each array supports a maximum of 1 GBASE-T/iSCSI ports Total number			24
Maximum 10/25 supported per array Total number of GbE/iSCSI ports			24
Maximum original capacity			8.0PB
Maximum number of SAN hosts			1,024
Maximum pool number			40
Maximum number of luns per array			2000
Maximum LUN size			256 TB
The maximum file system for each array quantity			2000
Maximum file system size			256 TB
Maximum attached snapshot for each array Quantity (data block)			2000

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Xiamen DongChengXing Information Technology Co., Ltd., established in 2019, provides various computer and server hardware, IT products import and export trade! Our core business is supply hardware and software, such as DELL, EMC, Inspur, Lenovo switches, servers, storage, routers, network modules, firewalls, wireless ap, memory, providing intelligent overall solution for the engine room to customers. We provide higher and better IT services for users of different groups. 24-hour service: in order to support the work and daily use of customers, and provide free remote assistance, telephone support. Our goal is to become the most satisfied it service provider for all users. Our philosophy: "Honesty, Mutual development, wholeheartedly for the customers", our company adhering to the customer first, service first business philosophy, with excellent quality of it services, exquisite technology, customer service team, to ensure the customer on the highway in the information age, make the customer while enjoy the latest achievements of information technology to develop continuously to obtain the biggest benefit.
