DELL Precision 7960 Tower Workstation

MODEL NUMBER1

Precision 7960 Tower

CHIPSET

Intel W790

PROCESSOR
OPTIONS1

Intel® Xeon® w9-3495X (105MB Cache, 56 cores, 112 threads, 1.9GHz to 4.8GHz Turbo 350W)
Intel® Xeon® w9-3475X (82.5MB Cache, 36 cores, 72 threads, 2.2GHz to 4.8GHz Turbo 300W)
Intel® Xeon® w7-3465X (75MB Cache, 28 cores, 56 threads, 2.5GHz to 4.8GHz Turbo 300W)
Intel® Xeon® w7-3455 (67.5MB Cache, 24 cores, 48 threads, 2.5GHz to 4.8GHz Turbo 270W)
Intel® Xeon® w7-3445 (52.5MB Cache, 20 cores, 40 threads, 2.6GHz to 4.8GHz Turbo 270W)
Intel® Xeon® w5-3435X (45MB Cache,16 cores, 32 threads, 3.1GHz to 4.7GHz Turbo 270W)
Intel® Xeon® w5-3425 (30MB Cache, 12 cores, 24 threads, 3.2GHz to 4.6GHz Turbo 270W)
Intel® Xeon® w5-3433 (45MB Cache, 16 cores, 32 threads 2.0GHz to 4.2GHz Turbo 220W)
Intel® Xeon® w5-3423 (30MB Cache,12 cores, 24 threads, 2.1GHz to 4.2GHz Turbo 220W)

GRAPHICS

NVIDIA:
NVIDIA® RTX™ A800 40GB GDDR6 - no display output - requires T1000 for display
NVIDIA® RTX™ 6000 ADA 48GB GDDR6
NVIDIA® RTX™ A6000, 48GB GDDR6
NVIDIA® RTX™ A5500, 24GB GDDR6
NVIDIA® RTX™ 5000 ADA 32GB GDDR6
NVIDIA® RTX™ A4500 ADA 24GB GDDR6
NVIDIA® RTX™ A4500, 20GB GDDR6
NVIDIA® RTX™ 4000 ADA 20GB GDDR6
NVIDIA® RTX™ A4000, 16GB GDDR6
NVIDIA® RTX™ A2000, 12GB GDDR6
NVIDIA® T1000, 8GB GDDR6
NVIDIA® T400, 4GB GDDR6
AMD:
AMD Radeon Pro™ W7900 48GB GDDR6
AMD Radeon™ Pro W6800, 32GB GDDR6
AMD Radeon™ Pro W6600, 8GB GDDR6
AMD Radeon™ Pro W6400, 4GB GDDR6

OPERATING SYSTEM1

Windows 11 for Workstations
Ubuntu® 22.04, 64-bit
Red Hat® Linux® 8.6 Enterprise WS

MEMORY OPTIONS1,2,3

16GB, 1 x 16GB, DDR5, 4800MHz, ECC
32GB, 1 x 32GB, DDR5, 4800MHz, ECC
32GB, 2 x 16GB, DDR5, 4800MHz, ECC
64GB, 1 x 64GB, DDR5, 4800MHz, ECC
64GB, 2 x 32GB, DDR5, 4800MHz, ECC
64GB, 4 x 16GB, DDR5, 4800MHz, ECC
96GB, 6 x 16GB, DDR5, 4800MHz, ECC
128GB, 1 x 128GB, DDR5, 4800MHz, ECC
128GB, 2 x 64GB, DDR5, 4800MHz, ECC
128GB, 4 x 32GB, DDR5, 4800MHz, ECC
128GB, 8 x 16GB, DDR5, 4800MHz, ECC
192GB, 6 x 32GB, DDR5, 4800MHz, ECC
192GB, 12 x 16GB, DDR5, 4800MHz, ECC
256GB, 1 x 256GB, DDR5, 4800MHz, ECC
256GB, 2 x 128GB, DDR5, 4800MHz, ECC
256GB, 4 x 64GB, DDR5, 4800MHz, ECC
256GB, 8 x 32GB, DDR5, 4800MHz, ECC
256GB, 16 x 16GB, DDR5, 4800MHz, ECC
384GB, 6 x 64GB, DDR5, 4800MHz, ECC
384GB, 12 x 32GB, DDR5, 4800MHz, ECC
512GB, 2 x 256GB, DDR5, 4800MHz, ECC
512GB, 4 x 128GB, DDR5, 4800MHz, ECC
512GB, 8 x 64GB, DDR5, 4800MHz, ECC
512GB, 16 x 32GB, DDR5, 4800MHz, ECC
768GB, 6 x 128GB, DDR5, 4800MHz, ECC
768GB, 12 x 64GB, DDR5, 4800MHz, ECC
1 TB, 4 x 256GB, DDR5, 4800MHz, ECC
1 TB, 8 x 128GB, DDR5, 4800MHz, ECC
1 TB, 16 x 64GB, DDR5, 4800MHz, ECC
1.5 TB, 6 x 256GB, DDR5, 4800MHz, ECC
1.5 TB, 12 x 128GB, DDR5, 4800MHz, ECC
2 TB, 8 x 256GB, DDR5, 4800MHz, ECC
2 TB, 16 x 128GB, DDR5, 4800MHz, ECC
3 TB, 12 x 256GB, DDR5, 4800MHz, ECC
4 TB, 16 x 256GB, DDR5, 4800MHz, ECC
16 DIMM slots across 8 Memory Channels per CPU
Memory clocks down to 4400MHz or lower (CPU dependent) in configurations with 2 DIMMs per channel

BOOT DRIVES1,5

M.2 2280, 512GB, PCIe NVMe Gen4 x4, SSD, Class 40
M.2 2280, 1TB, PCIe NVMe Gen4 x4, SSD, Class 40
M.2 2280, 2TB, PCIe NVMe Gen4 x4, SSD, Class 40
M.2 2280, 4TB, PCIe NVMe Gen4 x4, SSD, Class 40

STORAGE
CONTROLLERS

Integrated: Intel chipset 6Gb/s SATA controller supporting up to 8 ports for SATA HDD/SSD. 1 port for optical drive.
Intel vROC SW SATA RAID 0,1,5,10 supported across up to 8 SATA ports
Integrated Intel chipset controller supports up to 8 M.2 NVMe drives in 4 externally-facing FlexBays or up to 8 M.2 NVMe drives in
2 Dell Ultra-Speed
Drive Quad x16 PCIe cards.
Optional Intel vROC Standard SW NVMe RAID 0,1,10 option - (motherboard activation key) for M.2 NVMe PCIe SSDs in FlexBays or on
Ultra-Speed Drive
Quad x16 or Duo x8 card (0,1).
Maximum 4 drives per RAIDset. Supports 2 FlexBay NVMe RAIDsets - up to 4 drives in front and up to 4 drives in rear Flexbays,
Optional Intel vROC Premium SW NVMe RAID 0,1,5,10 option adds RAID 5
Optional MegaRAID 9660 SATA/SAS HW RAID controller. RAID 0,1,5,10.
Supports up to 10 SATA/SAS drives or up to 4 M.2 NVMe drives in front FlexBays.
Optional MegaRAID 9540 SATA/SAS RAID controller. RAID 0,1,10. Supports up to 8 SATA/SAS drives

CASE COLOR

Dell Standard Black

PRODUCTIVITY
SOFTWARE1

Microsoft Office Home and Business 2021
Microsoft Office Professional 2021 - Commercial
Dell Optimizer for Precision

ACCIDENTAL DAMAGE
SERVICES

3-year Accidental Damage Service
4-year Accidental Damage Service
5-year Accidental Damage Service

CHASSIS

Full-size tower - 19” Rack Mount Kit available (Takes 5U rack space)

PORTS

Front:
(2) USB 3.2 Gen 1 ports
USB 3.2 Gen 2 Type-C port with PowerShare
USB 3.2 Gen 2 Type-C port
Universal audio port
SD-card slot
Rear:
(3) USB 3.2 Gen 2 Type-C ports
(2) USB 3.2 Gen 1 ports
USB 3.2 Gen 1 port with Smart Power On
RJ45 Ethernet port, 1GBE
RJ45 Ethernet port, 10GBE
Line-out port
Serial port
(2) PS2 ports

OPTICAL DRIVE

8x DVD-ROM 9.5mm optical drive
8x DVD+/-RW 9.5mm optical drive
16x DVD+/-RW half-height optical drive

SLOTS

2 full-height Gen5 PCIe x16 slots
2 full-height Gen4 PCIe x16 slots
2 full-height Gen4 PCIe x8 slots
2 full-height, half length Gen4 PCIe x8 slots wired as x4 electrically
8 Externally facing (4 front, 4 rear) drive bays with optical drive configuration
10 Externally facing (6 front, 4 rear) drive bays without optical drive configuration Up to 8 M.2 NVMe drives (4 in front, 4 in
rear)

ADD-IN CARDS

Intel® Ethernet Network Adapter X710GBE NIC Card
Intel® Ethernet Network Adapter i225 2.5GBE NIC Card
ThunderboltTM 4 PCIe card
Dell Precision Ultra-Speed Drive Quad (x16) and Duo (x8) PCIe cards support M.2 NVMe drives with active cooling with up to 4 and 2
NVMe drives respectively
Broadcom MegaRAID 9540 SATA/SAS RAID controller
Broadcom MegaRAID 9660 SATA/SAS HW RAID controller (also supports up to 4 M.2 NVMe drives in front FlexBays.)
Qualcomm® WCN6856-DBS Wi-FI 6E, Bluetooth 5.3 wireless LAN card
USB 3.1 PCIe card

DIMENSIONS

U.S.
Height: 16.96in. / 17.09in. with runner feet Width: 8.58in.
Depth: 21.19in. / 22.41in. with lock structure
Weight: Maximum: 82.82lbs. Typical: 52.50lbs. Minimum: 46.39lbs.
Rest of the world
Height: 430.70mm / 434.20mm with runner feet
Width: 218.00mm
Depth: 538.30mm / 569.15mm with lock structure
Weight: Maximum: 37.56kg Typical: 23.81kg Minimum: 21.04kg

AUDIO & SPEAKERS1

Realtek ALC3246-CGT Internal Speakers

WIRELESS

Qualcomm® WCN6856-DBS, 2x2 MIMO, 3571Mbps, 2.4GHz/5GHz/6GHz, Wi-Fi 6E (Wi-Fi 802.11ax), Bluetooth 5.2

POWER SUPPLIES

1100W (for AC input voltage of 108VAC - 180VAC) 1400W (input voltage 181VAC - 240VAC) –90% efficient (80PLUS Gold Certified).
1500W (for AC input voltage of 108VAC - 180VAC) 2200W (input voltage 181VAC - 240VAC) –90% efficient (80PLUS Platinum Certified).
1500W/2200W PSUs have C19 AC cord and require 20A circuit @115V or a 220V circuit
Externally accessible/removable/lockable

REGULATORY8,12

Product Safety, EMC and Environmental Datasheets:
https://www.dell.com/learn/sg/en/sgcorp1/product-info-datasheets-safety-emc-environmental
Dell Regulatory Compliance Home Page:
https://www.dell.com/learn/sg/en/sgcorp1/regulatory-compliance
Dell and the Environment:
https://www.dell.com/en-sg/dt/corporate/social-impact/advancing-sustainability/sustainable

HARDWARE SECURITY

Kensington security-cable slot
Padlock loop
Chassis lock support - Coin locker
Chassis intrusion switch
Optional lockable bezels for externally- facing front and rear storage FlexBays
TPM 2.0 Discrete Hardware

SECURITY SOFTWARE

McAfee® Small Business Security 30-Day Free Trial
McAfee® Small Business Security 12-month subscription
McAfee® Small Business Security 36 month subscription
Dell Encryption Personal
Dell Encryption Enterprise
Dell Encryption External Media
Dell Bitlocker Manager
Dell SafeGuard and Response VMW Carbonblack
Endpoint Standard

WARRANTY9,10

3-year Basic warranty with hardware service with on-site/in-home service after remote diagnosis
4-year Basic warranty with hardware service with on-site/in-home service after remote diagnosis
5-year Basic warranty with hardware service with on-site/in-home service after remote diagnosis
3-year ProSupport with Next Business Day on-site service
4-year ProSupport with Next Business Day on-site service
5-year ProSupport with Next Business Day on-site service
3-year ProSupport Plus for Client with Next Business Day on-site service
4-year ProSupport Plus for Client with Next Business Day on-site service
5-year ProSupport Plus for Client with Next Business Day on-site service

CONFIGURATION
SERVICES

Factory image load
BIOS customization
Hardware customization
Asset Tagging and Reporting

RECOMMENDED
ACCESSORIES

Mouse:
3Dconnexion SpaceMouse Wireless
Cables, Dongles, Adapters:
Dell Adapter - DisplayPort to HDMI 2.0 (4K)
Audio Headsets:
Dell Pro Wireless Headset - WL5022
Display:
Dell UltraSharp 27 Monitor - U2722D
Dell UltraSharp 32 HDR PremierColor Monitor - UP3221Q
Keyboards:
Dell Premier Multi-Device Wireless Keyboard and Mouse - KM7321W
Webcam:
Dell UltraSharp Webcam - WB7022
