Ideal for:
• Small to mid-sized businesses
• Enhanced thermal efficiency and quiet, office-friendly acoustics for remote office/branch office
• Collaboration and sharing
• Mail, messaging and file, print
Private Mold: | Yes | Products Status: | Stock |
---|---|---|---|
Type: | Tower | Processor Main Frequency: | 3.4GHz |
Processor Type: | Intel Xeon E2314 |
Feature | Technical Specifications |
Processor | One Intel Xeon E-2300 series processor with up to 8 cores or One Intel Pentium processor with up to 2 cores |
Memory | • Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s • Supports registered ECC DDR4 DIMMs only NOTE: For Pentium processor, maximum memory speed supported is 2666 MT/s |
Storage controllers | • Internal controllers (RAID): PERC H755, PERC H345, S150 • Internal Boot: Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs, USB • 12 Gbps SAS HBAs (non-RAID): internal - HBA355i, external - HBA355e |
Drive bays | 4 x 3.5-inch cabled SAS/SATA (HDD/SSDs) max 30.72 TB |
Power supplies | 300 W Bronze AC/240 V |
Fans | One cabled fan |
Dimensions | • Height: 360 mm (14.17 inches) • Width: 175 mm (6.88 inches) • Depth: 453.75 mm (17.86 inches) with bezel |
Form Factor | 4U tower server |
Embedded management | • iDRAC9 • iDRAC Direct • iDRAC RESTful with Redfish • iDRAC Service Module |
Bezel | Security bezel |
OpenManage Software | • OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin |
Mobility | OpenManage Mobile |
Integrations and Connections | OpenManage Integrations • BMC Truesight • Microsoft System Center • Red Hat Ansible Modules • VMware vCenter and vRealize Operations Manager |
OpenManage Connections | • IBM Tivoli Netcool/OMNIbus • IBM Tivoli Network Manager IP Edition • Micro Focus Operations Manager • Nagios Core • Nagios XI |
Security | • Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
Embedded NIC | 2 x 1 GbE LOM |
Ports | Front Ports • 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 3.0 |
Internal Ports • 1 x USB 3.0 | |
PCIe | 2 x PCIe Gen4 slots and 2 x PCIe Gen3 slots |
Operating System and Hypervisors | • Canonical Ubuntu Server LTS • Citrix Hypervisor • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi* * support only from Dec’21 For specifications and interoperability details, see Dell.com/OSsupport. |
